Reliable and Easy to use Magnetic Wire Tenioner for Stator Coil Winding Machine with big tension 500-2500g
Hangzhou Qianhe Precision Machinery Co.,Ltd
Qianhe is a professional manufacturer for coil winding tensioner, We offer Magnetic tensioner,electronic tensioner and servo tensioner
for coil winding machine with best quality and the most competitive price in china.
there is description about Magnetic tensioner as following:
Key advantages of Magnetic wire tensioners:
These magnetic tensioners use a device containing a permanent magnet as a
non-contact method of generating a variable resistance to rotation of the main
wheel of the tensioner, thus maintaining wire tension at the set value for longer
periods than their mechanical counterparts with greatly reduced requirement for
adjustment.
- Polished ceramic eyelets and guide rollers at each point of contact protect the insulating enamel from mechanical damage.
- The performance of these magnetic wire tensioners is exceptional given the low cost,
- providing outstanding value for money.
- Captive roller on tension arm is easy to thread, eliminates chance of losing wire.
Specification :
| Products Series | Model | Tension Scope | Applied wire diameter | Tension Rod |
| (g) | (mm) |
| MTA Series (horizontal type) | QH-MTASS | 5-130 | 0.025-0.12 | TR-1# |
| QH-MTA300S | 14-400 | 0.06-0.25 | TR-5# |
| QH-MTAS | 30-800 | 0.08-0.40 | TR-6# |
| QH-MTAM | 300-1500 | 0.35-0.80 | TR-16# |
| QH-MTAL | 500-2500 | 0.40-1.00 | TR-21# |
Hanging line diagram
Tensioner test conditions :
Line speed is 15M/S, instant start, stop the continuous line, stable tension in the positive
and negative 1%g.
Key features of Type MTC300S :
- Tension Scope :500-2500g
- Applied wire diameter : 0.40-1.00
- Tension Rod : TR-21#
Picture show:
MTAL
Coil Winding Machine Tensioner
